Reflector antennas us a reflective object as intermediary between the radiating element and the far field pattern. For example: a corner reflector with a dipole or parabolic with a horn feed.
As usual all results: AS IS, no responsibility assumed.
A piece of metal in space.
A Plane Reflector
Usually a source antenna situated over reflective plane. The apex location and the angle between the planes determine the radiation pattern
A Corner Reflector
Usually a dipole antenna situated between two reflective planes. The apex location and the angle between the planes determine the radiation pattern
